Laundry sheet folder

Product Details

Intelligent controller with TOUCH SCREEN

With self-diagnosis function and self-management system, perfect safe protection system and self-maintenance for testing points

Programmable optional SINGLE, DOUBLE and FOUR lanes simultaneous folding

STANDARD 1st, 2nd and 3rd folds by air, 4th and 5th folds by Knife and blade; Optional 1st and 2nd fold by air, 3rd 4th and 5th folds by Knife and blade.

AUTOMATIC BELT TENSIONING in cross fold section and jam alarm in cross fold section

All valves are pneumatically control,“By pass” system

Precise and accurate folds, frequency inverter

Emergency stop buttons, production counters per lane.

High quality folding performance

Measurement by PHOTOELECTRIC SENSORS

Uses the HIGH INTELLIGENCE INFRARED TESTING SYSTEM to detect the size of linen and actual movement speed to improve the fold precision and accuracy.

With the function of FOUR CHANNELS FOLDING (TWO LATERAL FOLDS AND TWO CROSS FOLDS), this folder can improve the ironing and folding capacity of small linen, and lower the energy consumption.

China pioneering ANTI-STATIC BAR effectively reduces the static on the linen, to improve the folding performance and ensure stable and reliable operation.

With PATENTED REVERSE ANTI-STATIC DEVICE, it can remove the static on the belts, to avoid the adhesion of the linen and belts in the process of folding.

Variable speed synchronizes by speed of flatwork ironer; Working together with various flatwork ironer.

STACKER STATION is optional.
